919F Grader

Product Detail

Main Performance Parameters of 919F Grader

Overall weight (front and rear counterweight)	kg	14,365
Dimensions (basic)	mm	8,588x2,635x3,150
Maximum traction (f=0.8)	kN	83
Max. forward speed	km/h	40
Max. reverse speed	km/h	25
Engine type		Shangchai
Engine model		SC7H190G4
Rated power	kW	140
Rated RPM	rpm	2,200
Displacement	L	6.5
Emission standard		National four
Gear		Front 6 Rear 3
Hydraulic system		Load sensing, proportional priority, pressure compensation
Tyres*		Tubed bias tyres
Tyre specification		17.5-25
Rim specification		14.00/1.5
Minimum ground clearance of front axle	mm	630
Minimum turning radius (outside front wheels)	m	≤7.3
Shovel Float		Standard
Blade length**	m	3.96
Optional working device		Front push shovel, rear soil splitter
*Basic tyres with a wide range of tyre options ‘Three lengths are available: 3.66, 3.96, 427m Please contact your local agent for details.
